Mounting Motor Plates

The above motors are held with a pair of Motor plates (see below) when using 1/2" diameter axles running in Oilite bushes (SDSP012), with Mod 1 gears (SDSP006).
Each motor/ wheel set requires one plate threaded M5 and one plate drilled for M5 clearance. - When assembled with our smaller motor (SDSP001), it will fit between 5" gauge wheel sets.
Plates have a 5mm diameter hole for the attachment of anchor links to provide articulated motor mounting when used with a sprung axle.
Plates are designed to maintain the correct centres so that the gears mesh correctly, with our motors and bushes.
